Unit Suhu Tinggi FRASCOLD SPA
Unit skru suhu tinggi FRASCOLD SPA ialah penyelesaian penyejukan bersepadu yang direka bentuk untuk aplikasi suhu penyejatan sederhana hingga tinggi, dengan pengoptimuman yang disasarkan dalam struktur sistem, kestabilan operasi dan konfigurasi komprehensif. Unit ini menggunakan reka bentuk bersepadu yang padat, menggabungkan pemampat skru, sistem pemisahan minyak, peranti penyejukan dan sistem kawalan ke dalam unit yang sangat padat. Reka bentuk ini bukan sahaja memastikan prestasi penyejukan yang optimum tetapi juga menjimatkan ruang dalam bilik jentera dengan berkesan. Konfigurasi bersepadu memudahkan proses pemasangan di tapak dan menyediakan keadaan yang mudah untuk penyelenggaraan dan servis seterusnya, menjadikannya ideal untuk projek penyejukan di mana penggunaan ruang dan pengurusan peralatan menjadi pertimbangan utama.
Dari segi konfigurasi kuasa teras, unit ini dilengkapi dengan pemampat skru separa hermetik daripada jenama domestik dan antarabangsa yang terkenal. Pemampat ini mempunyai teknologi matang, kecekapan operasi yang stabil, dan mampu beroperasi secara berterusan dan berterusan di bawah keadaan suhu sederhana hingga tinggi. Pemampat direka untuk meminimumkan getaran dan mengurangkan tahap hingar, yang membantu menambah baik persekitaran kerja bilik jentera dan mengurangkan kesan ke atas kawasan sekitar. Reka bentuk mekanikal yang stabil juga menyumbang kepada hayat perkhidmatan yang dilanjutkan untuk pemampat, mengurangkan kekerapan penyelenggaraan semasa operasi.
Pengenalan Parameter Peralatan
Paparan Terperinci
Hubungi Kami
Pengenalan Parameter Peralatan
| Model Unit | Com.Model | Com. Curtity | Pemeluwapan temp. (℃) | Suhu Penyejatan. (℃) | takungan (L) | Bekalan paip (mm) | sedutan paip (mm) | Outiet Gas paip (mm) | cecair paip masuk (mm) | Dimensi (mm) (L×W×H) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasiti Penyejukan/Input Kuasa (kw) | |||||||||||||||||||
| LXPL-FSF-40H | RTSH-40 -120Y (40HP) | 1 | 35 | 60.6 | 21.5 | 23.4 | 22.2 | 88.3 | 23.4 | 1053 | 24.9 | 124.7 | 26.4 | 60 | Φ28 | Φ54 | Φ42 | Φ28 | 2300×1000×1500 |
| 40 | 54.2 | 25.6 | 66.2 | 26.1 | 79.9 | 27.1 | 95.7 | 28.4 | 113.7 | 29.9 | |||||||||
| 45 | 46.6 | 31.1 | 57.6 | 31.2 | 70.1 | 32.5 | 84.5 | 34.0 | 100.9 | 35.6 | |||||||||
| LXPL-BFSF2 -80H | 2 | 35 | 121.2 | 43.0 | 146.8 | 44.4 | 176.6 | 46.8 | 210.6 | 49.8 | 299.4 | 52.8 | 120 | Φ28 | Φ89 | Φ54 | Φ35 | 2500×1800×1800 | |
| 40 | 108.4 | 51.2 | 132.4 | 52.2 | 159.8 | 54.2 | 191.4 | 56.8 | 227.4 | 59.8 | |||||||||
| 45 | 93.2 | 62.2 | 115.2 | 62.4 | 140.2 | 65.0 | 169.0 | 68.0 | 201.8 | 71.2 | |||||||||
| LXPL-BFSF3 -120H | 3 | 35 | 181.8 | 64.5 | 202.2 | 66.6 | 264.9 | 70.2 | 315.9 | 74.7 | 374.1 | 79.2 | 150 | Φ35 | Φ76×2 | Φ89 | Φ42 | 3200×1800×1800 | |
| 40 | 162.6 | 76.8 | 198.6 | 78.3 | 239.7 | 81.3 | 287.1 | 85.2 | 341.1 | 89.7 | |||||||||
| 45 | 139.8 | 93.3 | 172.8 | 93.6 | 210.3 | 97.5 | 253.5 | 102.0 | 302.7 | 106.8 | |||||||||
| LXPL-BFSF4 -160H | 4 | 35 | 242.4 | 86.0 | 293.6 | 88.8 | 353.2 | 931.6 | 421.2 | 99.6 | 498.8 | 150.6 | 200 | Φ35 | Φ89×2 | Φ89 | Φ42 | 3900×1800×1800 | |
| 40 | 216.8 | 102.4 | 264.8 | 104.4 | 319.6 | 108.4 | 382.8 | 113.6 | 454.8 | 119.6 | |||||||||
| 45 | 186.4 | 124.4 | 230.4 | 124.8 | 280.4 | 130.0 | 338.0 | 136.0 | 403.6 | 142.4 | |||||||||
| LXPL-FSF-50H | RTSH-50 -150Y (50HP) | 1 | 35 | 74.8 | 24.9 | 90.8 | 26.0 | 109.2 | 27.2 | 130.3 | 28.3 | 154.6 | 29.1 | 80 | Φ28 | Φ89 | Φ42 | Φ22 | 2300×1000×1500 |
| 40 | 67.4 | 29.1 | 82.1 | 30.8 | 99.1 | 31.5 | 118.6 | 33.0 | 140.9 | 34.5 | |||||||||
| 45 | 59.7 | 37.2 | 73.1 | 37.7 | 88.6 | 38.9 | 106.4 | 40.5 | 126.8 | 42.4 | |||||||||
| LXPL-BFSF2 -100H | 2 | 35 | 149.6 | 49.8 | 181.6 | 52.0 | 218.4 | 54.4 | 260.6 | 56.6 | 309.2 | 58.2 | 150 | Φ28 | Φ89 | Φ89 | Φ35 | 2500×1800×1800 | |
| 40 | 134.8 | 58.2 | 164.2 | 61.6 | 198.2 | 63.0 | 237.2 | 66.0 | 281.8 | 69.0 | |||||||||
| 45 | 119.4 | 74.4 | 146.2 | 75.4 | 177.2 | 77.8 | 252.8 | 81.0 | 753.6 | 84.8 | |||||||||
| LXPL-FSF3 -150H | 3 | 35 | 224.4 | 74.7 | 272.4 | 78.0 | 327.6 | 81.6 | 39.09 | 84.9 | 463.8 | 87.3 | 200 | Φ35 | Φ89 ×2 | Φ89 | Φ42 | 3200×1800×1800 | |
| 40 | 202.2 | 87.3 | 246.3 | 92.4 | 297.3 | 94.5 | 3558 | 99.0 | 422.7 | 103.5 | |||||||||
| 45 | 179.1 | 111.6 | 219.3 | 113.1 | 256.8 | 116.7 | 319.2 | 121.5 | 380.4 | 127.2 | |||||||||
| LXPL-BFSF4 -200H | 4 | 35 | 299.2 | 99.6 | 363.2 | 104.0 | 436.0 | 108.8 | 521.2 | 113.2 | 618.4 | 117.6 | 250 | Φ42 | Φ108 ×2 | Φ108 | Φ54 | 3900×1800×1800 | |
| 40 | 2696 | 116.4 | 328.4 | 123.2 | 396.4 | 126.0 | 474.4 | 132.0 | 563.6 | 138.0 | |||||||||
| 45 | 238.8 | 148.8 | 297.4 | 150.8 | 354.4 | 155.6 | 425.6 | 1620 | 507.2 | 169.6 | |||||||||
| LXPL-FSF-50H | NRH2-60 -186Y (60HP) | 1 | 35 | 92.5 | 30.6 | 112.2 | 31.6 | 135.0 | 33.1 | 161.2 | 34.4 | 191.2 | 35.6 | 80 | Φ28 | Φ89 | Φ54 | Φ28 | 2300×1000×1500 |
| 40 | 82.6 | 35.7 | 100.7 | 36.7 | 121.7 | 38.1 | 145.7 | 39.7 | 173.2 | 41.3 | |||||||||
| 45 | 71.0 | 43.2 | 87.7 | 44.2 | 106.8 | 45.7 | 128.8 | 47.6 | 153.4 | 50.0 | |||||||||
| LXPL-BFSF2 -100H | 2 | 35 | 185.0 | 61.2 | 224.4 | 63.2 | 270.0 | 66.2 | 322.4 | 68.8 | 382.4 | 71.2 | 200 | Φ35 | Φ108 | Φ89 | Φ42 | 2500×2000×1850 | |
| 40 | 165.2 | 71.4 | 201.4 | 73.4 | 243.4 | 76.2 | 291.4 | 79.4 | 346.4 | 82.4 | |||||||||
| 45 | 142.0 | 86.4 | 175.4 | 88.4 | 213.6 | 91.4 | 257.6 | 95.2 | 306.8 | 100.0 | |||||||||
| LXPL-BFSF3 -150H | 3 | 35 | 277.5 | 91.8 | 336.6 | 94.8 | 405.0 | 99.3 | 483.6 | 103.2 | 573.6 | 106.8 | 250 | Φ42 | Φ108 ×2 | Φ89 | Φ54 | 4100×1950×1750 | |
| 40 | 247.8 | 107.1 | 302.1 | 110.1 | 365.1 | 114.3 | 437.1 | 119.1 | 519.6 | 123.6 | |||||||||
| 45 | 213.0 | 129.6 | 263.1 | 132.6 | 320.4 | 137.1 | 386.4 | 142.8 | 460.2 | 150.0 | |||||||||
| LXPL-BFSF4 -200H | 4 | 35 | 370.0 | 122.4 | 448.8 | 126.4 | 540.0 | 132.4 | 644.8 | 137.6 | 764.8 | 142.4 | 400 | Φ42 | Φ108 ×2 | Φ108 | Φ54 | 4950×1950×1800 | |
| 40 | 330.4 | 142.8 | 402.8 | 146.8 | 488.8 | 157.4 | 582.8 | 158.8 | 692.8 | 164.8 | |||||||||
| 45 | 284.0 | 172.8 | 350.8 | 176.8 | 427.2 | 182.8 | 515.2 | 190.4 | 613.6 | 200.0 | |||||||||
| Model Unit | Cam.Model | Cam, Cuartity | Pemeluwapan temp. (℃） | Suhu Penyejatan (℃) | takungan (L) | Bekalan paip (mm) | sedutan paip (mm) | Outiet Gas paip (mm) | cecair paip masuk (mm) | Dimensi (mm) (LxW×H) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasiti Penyejukan/Input Kuasa (kw) | |||||||||||||||||||
| LXPL-FSF-70H | NRH2-70 -210Y (70HP) | 1 | 35 | 103.3 | 33.9 | 126.3 | 35.7 | 153.0 | 37.4 | 183.7 | 38.7 | 218.9 | 394 | 100 | Φ28 | Φ89 | Φ54 | Φ28 | 2300×1000×1500 |
| 40 | 91.0 | 39.2 | 111.9 | 41.3 | 136.1 | 43.6 | 163.9 | 45.7 | 195.8 | 47.5 | |||||||||
| 45 | 78.1 | 46.6 | 97.0 | 48.7 | 118.7 | 51.2 | 143.7 | 53.8 | 172.3 | 56.4 | |||||||||
| LXPL-BFSF2 -140H | 2 | 35 | 206.6 | 67.8 | 252.6 | 71.4 | 306.0 | 74.8 | 367.4 | 77.4 | 437.8 | 78.8 | 200 | Φ35 | Φ133 | Φ89 | Φ42 | 2500×1800×1800 | |
| 40 | 182.0 | 78.4 | 223.8 | 82.6 | 272.2 | 87.2 | 327.8 | 91.4 | 391.6 | 95.0 | |||||||||
| 45 | 156.2 | 93.2 | 194.0 | 97.4 | 237.4 | 102.4 | 287.4 | 107.6 | 344.6 | 112.8 | |||||||||
| LXPL-BFSF3 -210H | 3 | 35 | 309.9 | 101.7 | 378.9 | 107.1 | 459.0 | 112.2 | 551.1 | 116.1 | 656.7 | 118.2 | 300 | Φ42 | Φ108 ×2 | Φ108 | Φ54 | 3200×1850×1800 | |
| 40 | 273.0 | 117.6 | 335.7 | 123.9 | 408.3 | 130.8 | 491.7 | 137.1 | 587.4 | 142.5 | |||||||||
| 45 | 156.2 | 139.8 | 291.0 | 146.1 | 356.1 | 153.6 | 431.1 | 161.4 | 516.9 | 169.2 | |||||||||
| LXPL-BFSF4 -280H | 4 | 35 | 413.2 | 135.6 | 505.2 | 142.8 | 612.0 | 149.6 | 734.8 | 154.8 | 875.6 | 157.6 | 400 | Φ54 | Φ133 ×2 | Φ108 | Φ67 | 3900×1850×1800 | |
| 40 | 364.0 | 156.8 | 447.6 | 165.7 | 544.4 | 174.4 | 655.6 | 182.8 | 783.2 | 190.0 | |||||||||
| 45 | 312.4 | 186.4 | 388.0 | 194.8 | 474.8 | 240.8 | 574.8 | 215.2 | 689.2 | 225.6 | |||||||||
| LXPL-FSF-80H | NRH3-80 -240Y (80HP) | 1 | 35 | 123.0 | 38.9 | 149.3 | 40.7 | 179.6 | 43.7 | 214.5 | 46.2 | 254.2 | 49.4 | 150 | Φ28 | Φ89 | Φ54 | Φ28 | 2300×1000×1500 |
| 40 | 109.0 | 46.5 | 132.9 | 47.8 | 160.5 | 50.6 | 192.2 | 52.7 | 228.5 | 55.6 | |||||||||
| 45 | 94.3 | 56.6 | 115.9 | 58.2 | 140.6 | 60.9 | 169.1 | 641.1 | 201.6 | 67.6 | |||||||||
| LXPL-BFSF2 -160H | 2 | 35 | 246.0 | 77.8 | 298.6 | 81.4 | 359.2 | 87.4 | 429.0 | 92.4 | 508.4 | 98.8 | 250 | Φ35 | Φ133 | Φ89 | Φ42 | 2500×2000×1850 | |
| 40 | 218.0 | 93.0 | 265.8 | 95.6 | 321.0 | 100.2 | 384.4 | 150.4 | 457.0 | 111.2 | |||||||||
| 45 | 188.6 | 113.2 | 231.8 | 116.4 | 261.2 | 121.8 | 338.2 | 128.2 | 403.2 | 1352 | |||||||||
| LXPL-FSF3 -240H | 3 | 35 | 369.0 | 116.7 | 447.9 | 122.1 | 538.8 | 131.1 | 643.5 | 138.6 | 762.6 | 148.2 | 400 | Φ42 | Φ108 ×2 | Φ108 | Φ54 | 4100×1950×1800 | |
| 40 | 327.0 | 139.5 | 398.7 | 143.4 | 481.5 | 151.8 | 576.6 | 158.1 | 685.5 | 166.8 | |||||||||
| 45 | 282.9 | 169.8 | 347.7 | 174.6 | 421.8 | 182.7 | 507.3 | 192.3 | 604.8 | 202.6 | |||||||||
| LXPL-BFSF4 -320H | 4 | 35 | 492.0 | 155.6 | 597.2 | 162.8 | 718.4 | 174.8 | 858.0 | 184.8 | 1016.8 | 197.6 | 500 | Φ54 | Φ133 ×2 | Φ108 | Φ67 | 4950×1950×1800 | |
| 40 | 436.0 | 186.0 | 531.6 | 191.2 | 642.0 | 202.4 | 768.8 | 210.8 | 914.0 | 222.4 | |||||||||
| 45 | 377.2 | 226.4 | 463.6 | 232.8 | 562.4 | 243.6 | 676.4 | 256.4 | 806.4 | 270.4 | |||||||||
| LXPL-FSF-90H | NRH3-90 -270Y (90HP) | 1 | 35 | 137.2 | 44.5 | 166.9 | 246.6 | 201.3 | 49.2 | 240.9 | 52.0 | 286.2 | 54.6 | 150 | Φ28 | Φ89 | Φ67 | Φ28 | 2600×1000×1500 |
| 40 | 121.2 | 52.4 | 148.4 | 54.3 | 179.8 | 56.9 | 215.9 | 60.0 | 257.2 | 63.0 | |||||||||
| 45 | 104.8 | 63.3 | 129.2 | 65.4 | 157.3 | 68.4 | 189.7 | 72.0 | 226.7 | 75.7 | |||||||||
| LXPL-BFSF2 -180H | 2 | 35 | 274.4 | 89.0 | 333.8 | 93.2 | 402.6 | 98.4 | 481.8 | 104.0 | 572.4 | 109.2 | 250 | Φ42 | Φ133 | Φ89 | Φ54 | 2500×2000×1850 | |
| 40 | 242.4 | 104.8 | 296.8 | 108.6 | 359.6 | 113.8 | 431.8 | 120.0 | 514.4 | 126.0 | |||||||||
| 45 | 209.6 | 126.6 | 258.4 | 130.8 | 314.0 | 136.8 | 379.4 | 144.0 | 453.4 | 151.4 | |||||||||
| LXPL-BFSF3 -270H | 3 | 35 | 411.6 | 133.5 | 500.7 | 139.8 | 803.9 | 147.6 | 722.7 | 156.0 | 858.0 | 163.8 | 400 | Φ42 | Φ108 ×2 | Φ108 | Φ54 | 3200×2100×1900 | |
| 40 | 363.6 | 157.2 | 445.2 | 162.9 | 539.4 | 170.7 | 647.7 | 180.0 | 771.6 | 189.0 | |||||||||
| 45 | 314.4 | 189.9 | 387.6 | 196.2 | 471.9 | 205.2 | 569.1 | 216.0 | 680.1 | 227.1 | |||||||||
| LXPL-BFSF4 -360H | 4 | 35 | 548.8 | 178.0 | 676.6 | 186.4 | 805.2 | 196.8 | 963.6 | 208.0 | 1144.8 | 1218.4 | 500 | Φ54 | Φ133 ×2 | Φ133 | Φ67 | 4950×1950×1800 | |
| 40 | 484.8 | 209.6 | 593.6 | 217.2 | 719.2 | 227.6 | 863.6 | 240.01 | 1028.8 | 252.0 | |||||||||
| 45 | 419.2 | 253.2 | 516.8 | 261.6 | 629.2 | 273.6 | 758.8 | 288.0 | 906.8 | 302.8 | |||||||||
| Model Unit | Com.Model | Com. Curtity | Pemeluwapan temp. (℃) | Suhu Penyejatan. (℃) | takungan (L) | Bekalan paip (mm) | sedutan paip (mm) | Outiet Gas paip (mm) | cecair paip masuk (mm) | Dimensi (mm) (L×W×H) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasiti Penyejukan/Input Kuasa (kw) | |||||||||||||||||||
| LXPL-FSF -100H | NRH4-100 -300Y (100HP) | 1 | 35 | 152.5 | 47.9 | 185.3 | 50.0 | 223.3 | 52.9 | 267.0 | 55.9 | 316.9 | 58.8 | 150 | Φ35 | Φ89 | Φ67 | Φ35 | 2600×1000×1500 |
| 40 | 135.1 | 56.5 | 165.1 | 58.6 | 199.8 | 61.5 | 240.0 | 64.8 | 285.2 | 68.3 | |||||||||
| 45 | 116.9 | 68.5 | 143.9 | 70.9 | 175.0 | 74.2 | 210.9 | 78.3 | 252.0 | 82.6 | |||||||||
| LXPL-BFSF2 -200H | 2 | 35 | 305.0 | 95.8 | 370.6 | 100.0 | 446.6 | 105.8 | 534.0 | 111.8 | 633.8 | 117.6 | 300 | Φ42 | Φ133 | Φ108 | Φ54 | 2500×2100×1850 | |
| 40 | 270.2 | 113.0 | 330.2 | 117.2 | 399.6 | 123.0 | 480.0 | 129.6 | 570.4 | 133.6 | |||||||||
| 45 | 233.8 | 137.0 | 287.8 | 141.8 | 350.0 | 148.4 | 421.8 | 156.6 | 504.0 | 165.2 | |||||||||
| LXPL-BFSF3 -300H | 3 | 35 | 457.5 | 143.7 | 555.9 | 150.0 | 669.9 | 158.7 | 801.0 | 167.7 | 950.7 | 176.4 | 500 | Φ54 | Φ133 ×2 | Φ108 | Φ67 | 3200×2150×1900 | |
| 40 | 405.3 | 169.5 | 395.3 | 175.8 | 599.4 | 184.5 | 720.0 | 194.4 | 855.6 | 204.9 | |||||||||
| 45 | 350.7 | 205.5 | 431.7 | 212.7 | 525.0 | 222.6 | 632.1 | 234.9 | 756.0 | 247.8 | |||||||||
| LXPL-BFSF4 -400H | 4 | 35 | 610.0 | 191.6 | 741.2 | 200.0 | 893.2 | 211.6 | 106.8 | 223.6 | 1267.6 | 235.2 | 600 | Φ67 | Φ133 ×2 | Φ133 | Φ76 | 1950×1950×1800 | |
| 40 | 540.4 | 266.0 | 660.4 | 234.4 | 799.2 | 246.0 | 960.0 | 259.2 | 1140.8 | 273.2 | |||||||||
| 45 | 467.6 | 274.0 | 575.6 | 283.6 | 700.0 | 296.8 | 843.6 | 313.2 | 1008.0 | 330.4 | |||||||||
| LXPL-FSF -120H | NRH5-120 -360Y (120HP) | 1 | 35 | 181.7 | 55.9 | 221.4 | 58.6 | 267.5 | 61.7 | 320.6 | 64.9 | 381.2 | 67.7 | 200 | Φ42 | Φ108 | Φ76 | Φ54 | 2300×1000×1500 |
| 40 | 160.8 | 65.1 | 197.0 | 67.5 | 238.9 | 70.8 | 287.0 | 74.6 | 342.1 | 78.2 | |||||||||
| 45 | 1392 | 78.1 | 171.7 | 80.7 | 2093 | 84.7 | 252.5 | 89.4 | 302.0 | 94.5 | |||||||||
| LXPL-BFSF2 -240H | 2 | 35 | 3634 | 111.8 | 442.8 | 117.2 | 535.0 | 123.4 | 641.2 | 129.8 | 762.4 | 135.4 | 400 | Φ54 | Φ159 | Φ108 | Φ67 | 2500×2000×1250 | |
| 40 | 321.6 | 130.2 | 394.0 | 135.0 | 477.8 | 141.6 | 514.0 | 149.2 | 684.2 | 156.4 | |||||||||
| 45 | 278.4 | 156.2 | 343.4 | 161.4 | 418.6 | 169.4 | 505.0 | 178.8 | 604.0 | 189.0 | |||||||||
| LXPL-FSF3 -360H | 3 | 35 | 545.1 | 167.7 | 664.2 | 175.8 | 802.5 | 185.1 | 961.8 | 194.7 | 1143.6 | 703.1 | 600 | Φ67 | Φ133 ×2 | Φ133 | Φ76 | 4100×1950×1850 | |
| 40 | 482.4 | 195.3 | 591.0 | 202.5 | 716.7 | 212.4 | 861.0 | 223.8 | 1026.3 | 234.6 | |||||||||
| 45 | 417.6 | 234.3 | 515.1 | 242.1 | 627.9 | 254.1 | 757.5 | 268.2 | 906.0 | 283.5 | |||||||||
| LXPL-BFSF4 -480H | 4 | 35 | 726.8 | 233.6 | 885.6 | 234.4 | 1070.0 | 246.8 | 1282.4 | 259.6 | 1524.8 | 270.8 | 800 | Φ76 | Φ159 ×2 | Φ133 | Φ89 | 4950×1950×1800 | |
| 40 | 643.2 | 264.0 | 755.0 | 270.0 | 955.0 | 283.2 | 1148.0 | 298.4 | 1368.4 | 312.8 | |||||||||
| 45 | 556.8 | 312.4 | 686.8 | 322.8 | 837.2 | 338.8 | 1010.0 | 357.6 | 120.8 | 378.0 | |||||||||
| LXPL-FSF -110H | NRH6-110 -316Y (110HP) | 1 | 35 | 136.8 | 50.9 | 204.2 | 52.6 | 251.1 | 54.7 | 301.5 | 57.3 | 352.2 | 60.3 | 200 | Φ42 | Φ108 | Φ76 | Φ54 | 2300×1000×1500 |
| 40 | 137.6 | 61.4 | 173.5 | 63.2 | 217.8 | 65.3 | 267.5 | 67.7 | 319.4 | 70.2 | |||||||||
| 45 | 112.8 | 734 | 140.6 | 75.9 | 178.6 | 78.4 | 224.0 | 81.0 | 273.4 | 83.7 | |||||||||
| LXPL-BFSF2 -220H | 2 | 35 | 327.6 | 101.8 | 408.4 | 1052 | 502.2 | 109.4 | 603.0 | 114.6 | 704.4 | 120.6 | 400 | Φ54 | Φ159 | Φ108 | Φ67 | 2500×2000×1850 | |
| 40 | 275.2 | 122.8 | 347.0 | 126.4 | 435.6 | 130.6 | 535.0 | 135.4 | 638.8 | 140.4 | |||||||||
| 45 | 225.6 | 164.8 | 281.2 | 151.8 | 357.2 | 156.8 | 448.0 | 162.0 | 546.8 | 167.4 | |||||||||
| LXPL-BFSF3 -330H | 3 | 35 | 491.4 | 152.7 | 612.6 | 157.8 | 753.3 | 164.1 | 904.5 | 171.9 | 1056.6 | 180.9 | 600 | Φ67 | Φ133 ×2 | Φ133 | Φ76 | 4100×1950×1850 | |
| 40 | 412.8 | 184.2 | 520.5 | 189.6 | 653.4 | 195.9 | 602.5 | 203.1 | 958.2 | 210.6 | |||||||||
| 45 | 338.4 | 220.2 | 421.8 | 227.7 | 535.8 | 235.2 | 672.0 | 243.0 | 820.0 | 751.1 | |||||||||
| LXPL-BFSF4 -440H | 4 | 35 | 655.2 | 203.6 | 816.8 | 210.4 | 1004.4 | 218.8 | 1206.0 | 229.2 | 1408.8 | 241.2 | 800 | Φ76 | Φ159 ×2 | Φ133 | Φ89 | 4950×1950×1800 | |
| 40 | 550.4 | 245.6 | 694.0 | 252.8 | 871.2 | 261.2 | 070.0 | 270.8 | 277.6 | 280.8 | |||||||||
| 45 | 451.2 | 293.6 | 552.4 | 303.6 | 714.4 | 313.6 | 896.0 | 324.0 | 1093.6 | 334.8 | |||||||||
| Model Unit | Com.Model | Com. Curtity | Pemeluwapan temp. (℃） | Suhu Penyejatan. (℃) | takungan (L) | Bekalan paip (mm) | sedutan paip (mm) | Outiet Gas paip (mm) | liauid paip masuk (mm) | Dimensi (mm) (L×W×H) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasiti Penyejukan/Input Kuasa(kw) | |||||||||||||||||||
| LXPL-FSF-125H | NRH6-125 -372Y (125HP) | 1 | 35 | 196.0 | 60.0 | 242.1 | 62.5 | 296.2 | 65.2 | 353.5 | 68.3 | 411.5 | 71.7 | 250 | Φ42 | Φ108 | Φ76 | Φ54 | 2300×1000×1500 |
| 40 | 166.8 | 73.1 | 75.9 | 260.5 | 78.7 | 316.6 | 871.7 | 374.9 | 285.2 | 84.8 | |||||||||
| 45 | 135.6 | 88.0 | 172.0 | 91.7 | 217.9 | 95.2 | 270.4 | 98.5 | 326.5 | 101.7 | |||||||||
| LXPL-BFSF2-250H | 2 | 35 | 392.0 | 120.0 | 485.4 | 125.0 | 592.4 | 130.4 | 707.0 | 136.6 | 823.0 | 143.4 | 400 | Φ54 | Φ159 | Φ108 | Φ67 | 2500×1800×1800 | |
| 40 | 333.6 | 146.2 | 419.0 | 151.8 | 521.0 | 157.4 | 633.2 | 163.4 | 749.8 | 169.6 | |||||||||
| 45 | 271.2 | 176.0 | 344.0 | 173.4 | 435.8 | 190.4 | 540.8 | 197.0 | 653.0 | 230.9 | |||||||||
| LXPL-BFSF3 -375H | 3 | 35 | 588.0 | 180.0 | 728.1 | 187.5 | 888.6 | 195.6 | 1060.5 | 204.9 | 1234.5 | 215.1 | 600 | Φ67 | Φ133 ×2 | Φ133 | Φ76 | 3200×1800×1800 | |
| 40 | 500.4 | 219.3 | 628.5 | 277.7 | 781.5 | 236.1 | 949.8 | 245.1 | 1124.7 | 254.4 | |||||||||
| 45 | 406.8 | 264.0 | 516.0 | 275.1 | 653.7 | 285.6 | 811.2 | 295.5 | 979.5 | 305.1 | |||||||||
| LXPL-BFSF4 -500H | 4 | 35 | 784.0 | 240.0 | 970.8 | 250.0 | 1184.8 | 260.8 | 1414.0 | 273.2 | 1646.0 | 286.8 | 800 | Φ76 | Φ159 ×2 | Φ133 | Φ89 | 3900×1800×1800 | |
| 40 | 667.2 | 292.4 | 638.0 | 303.6 | 1042.0 | 314.8 | 1266.4 | 326.8 | 1499.6 | 339.2 | |||||||||
| 45 | 542.4 | 352.0 | 688.0 | 368.8 | 871.6 | 380.8 | 1081.6 | 394.0 | 1306.0 | 406.8 | |||||||||
| LXPL-FSF -140H | NRH6-140 -428Y (140HP) | 1 | 35 | 228.7 | 69.6 | 280.1 | 72.0 | 340.1 | 74.6 | 405.1 | 77.3 | 470.5 | 80.0 | 300 | Φ54 | Φ108 | Φ76 | Φ67 | 2300×1000×1500 |
| 40 | 199.5 | 85.0 | 247.8 | 87.9 | 305.4 | 90.6 | 368.7 | 93.2 | 434.3 | 95.6 | |||||||||
| 45 | 164.9 | 101.7 | 207.2 | 105.9 | 261.0 | 109.7 | 320.2 | 113.2 | 383.8 | 1116.2 | |||||||||
| LXPL-BFSF2 -280H | 2 | 35 | 457.4 | 139.2 | 561.42 | 144.0 | 681.4 | 149.2 | 810.2 | 154.6 | 941.0 | 160.0 | 500 | Φ67 | Φ139 | Φ108 | Φ76 | 2500×1800×1800 | |
| 40 | 399.0 | 170.0 | 495.6 | 175.8 | 610.8 | 181.2 | 737.4 | 186.4 | 868.6 | 191.2 | |||||||||
| 45 | 329.8 | 203.4 | 414.4 | 211.8 | 520.2 | 219.4 | 640.4 | 226.4 | 767.6 | 232.4 | |||||||||
| LXPL-FSF3 -420H | 3 | 35 | 686.1 | 208.8 | 842.1 | 216.0 | 1022.1 | 223.8 | 1215.3 | 231.9 | 1411.5 | 240.0 | 800 | Φ76 | Φ133 ×2 | Φ133 | Φ89 | 3200×1800×1800 | |
| 40 | 598.5 | 255.0 | 743.4 | 263.7 | 916.2 | 271.8 | 1106.1 | 279.6 | 1302.9 | 286.8 | |||||||||
| 45 | 494.7 | 305.1 | 621.6 | 317.7 | 780.3 | 239.1 | 960.6 | 339.6 | 1151.4 | 348.6 | |||||||||
| LXPL-BFSF4 -560H | 4 | 35 | 914.8 | 278.4 | 1122.8 | 288.0 | 1362.8 | 298.4 | 1621.6 | 309.2 | 1882.0 | 320.0 | 1000 | Φ89 | Φ159 ×2 | Φ159 | Φ108 | 3900×1800×1800 | |
| 40 | 798.0 | 340.0 | 991.2 | 351.6 | 1221.6 | 362.4 | 1474.8 | 372.8 | 1737.2 | 382.9 | |||||||||
| 45 | 659.6 | 406.8 | 828.8 | 423.6 | 1040.4 | 438.8 | 1280.8 | 452.8 | 1535.2 | 464.8 | |||||||||
| LXPL-FSF -160H | NRH6-160 -468Y (160HP) | 1 | 35 | 250.4 | 76.1 | 306.7 | 78.7 | 371.3 | 81.5 | 441.3 | 84.5 | 513.7 | 87.5 | 300 | Φ54 | Φ159 | Φ108 | Φ67 | 2300×1000×1500 |
| 40 | 218.3 | 93.0 | 271.3 | 96.1 | 333.7 | 99.1 | 402.5 | 101.9 | 474.5 | 104.6 | |||||||||
| 45 | 180.2 | 111.2 | 227.5 | 115.8 | 285.2 | 120.0 | 350.2 | 123.8 | 419.3 | 127.1 | |||||||||
| LXPL-BFSF2 -320H | 2 | 35 | 500.8 | 152.2 | 613.4 | 157.4 | 742.6 | 163.0 | 882.6 | 169.0 | 1027.4 | 175.0 | 600 | Φ67 | Φ133 | Φ133 | Φ76 | 2500×2000×1850 | |
| 40 | 436.6 | 186.0 | 547.2 | 192.0 | 667.4 | 198.2 | 805.0 | 203.8 | 949.0 | 209.2 | |||||||||
| 45 | 360.4 | 222.4 | 455.0 | 231.6 | 570.4 | 240.0 | 700.4 | 247.6 | 838.6 | 254.2 | |||||||||
| LXPL-BFSF3 -480H | 3 | 35 | 751.2 | 228.3 | 921.0 | 236.1 | 1113.9 | 244.5 | 1323.9 | 253.5 | 1541.1 | 262.5 | 900 | Φ76 | Φ159 ×2 | Φ133 | Φ89 | 4100×1950×1750 | |
| 40 | 654.9 | 279.0 | 813.9 | 288.3 | 1001.1 | 297.3 | 1207.5 | 305.7 | 1423.5 | 313.8 | |||||||||
| 45 | 540.6 | 333.6 | 682.5 | 347.4 | 855.6 | 360.0 | 1050.6 | 371.4 | 1257.9 | 381.3 | |||||||||
| LXPL-BFSF4 -640H | 4 | 35 | 1001.6 | 304.4 | 1276.8 | 314.8 | 1485.2 | 326.0 | 1765.2 | 338.0 | 2054.8 | 350.0 | 1200 | Φ89 | Φ159 ×2 | Φ159 | Φ108 | 4950×1950×1800 | |
| 40 | 873.2 | 372.0 | 1085.2 | 384.4 | 1334.8 | 396.4 | 1610.0 | 401.6 | 1898.0 | 418.4 | |||||||||
| 45 | 720.8 | 444.8 | 910.0 | 463.2 | 140.8 | 480.0 | 1400.8 | 495.2 | 677.2 | 508.4 | |||||||||
Paparan Terperinci
Hubungi Kami
TENTANG KAMI
Zhejiang Lanxi Refrigeration Equipment Co., Ltd.
Sebagai China Unit Suhu Tinggi FRASCOLD SPA Pembekal dan Unit Suhu Tinggi FRASCOLD SPA Kilang,
Zhejiang Lanxi Refrigeration Equipment Co., Ltd. mengkhusus dalam penyelesaian penyejukan yang cekap, hijau, dan mampan. Dengan memanfaatkan produk berkualiti tinggi dan teknologi inovatif, kami melayani sektor makanan, farmaseutikal, kimia, dan logistik rantaian sejuk, mencipta sistem yang cekap tenaga dan mesra alam untuk pelanggan kami serta memupuk pembangunan saling menguntungkan untuk industri dan alam sekitar.
Sijil Kepujian
Berita
-
Apakah itu Penyejuk Udara Industri dan Bagaimana Ia Berfungsi dalam Sistem Penyejukan? Bayangkan sebuah bilik sejuk bersaiz sederhana yang dibina untuk menyimpan makanan sejuk beku pada suhu -22°C. Unit pemampat dan pemeluwap te...
BACA LANJUT -
Panduan Pemilihan Kondenser Lengkap: Pilih Pemeluwap yang Tepat untuk Sistem Perindustrian & HVAC Pemeluwap ialah komponen pemindahan haba teras yang digunakan secara meluas dalam sistem HVAC, penyejukan industri, pemprosesan kimia, p...
BACA LANJUT -
Panduan penyesuaian OEM pembekal kejuruteraan storan sejuk Apabila permintaan untuk pasaran tersegmen dalam industri rantaian sejuk luar negara meningkat, banyak pembekal dan peniaga kejuruteraan storan sejuk menyasarkan untuk mencipt...
BACA LANJUT
HUBUNGI KAMI
PAUTAN PANTAS
MAKLUMAT HUBUNGAN
- E-mel: [email protected]
- Telefon: +86-15258555916
- Alamat: 301 Punan Avenue, Pukou Street, Shengzhou City, Shaoxing City, Zhejiang Province.China
Hak Cipta © Zhejiang Lanxi Refrigeration Equipment Co., Ltd. Hak Cipta Terpelihara.
浙ICP备2022034605号-1
Borong Unit Suhu Tinggi FRASCOLD SPA Kilang
